- Place of Origin: china
- Brand Name: jiaxing
- Model Number: 60005
Features:
(1),low shrinkage ensure less crack during lamination, more quality products.
(2),high light transmittance let you have high photoelectric conversion efficiency.
(3),functional design, ideal cross linking degree ensure strength and dimension.
(4),anti—aging formulation , insulation ,UV-resistance, high and low temp resistance.
(5),passed TUV,CPVT,ISO:9001 certificate .
(6),good weatherability：25 years performance time
- Place of Origin: china
- Brand Name: jiaxing
- Model Number: 60005
NO | Testing item | unit | Test results |
1 | appearance | --- | Embossed,Surface flat,translucent,no stains,no bubbles,pattern clear. |
2 | Transmittance from 380nm to 1100nm | % | 90.7 |
3 | Total degree of cross linking | % | 79 |
4 | Tensile strength | Mpa | 20 |
5 | Elongation at a break | % | 529.5 |
6 | Shrinkage rate | % | MD:1.77 TD:0.3 |
7 | Volume resistivity | Ω.cm | 2.0*10^24 |
8 | Peel strength to glass | N/cm | 79 |
9 | Peel strength to TPT(Tedlar) | N/cn | 69 |
10 | Electrical breakdown strength | KV/mm | 35.3 |
11 | Water absorption rate | % | 0.01 |
12 | UV aging resistance test | ---- | YID:1.08 |
13 | Yellowness index Difference YID | <2.0 | |
14 | Damp heat test | ----- | YID:1.04 |
